Model:PJ-2460
Application:
Wooden flat board
Maximum 5 units of cutting motor,cutting board into 4 pieces
Cutting line
Size of board:3100*1240mm
Feature:
Two shorter sides trimming and board cutting in one machine
Maximum 5 sets of independent cutting motor,cutting 3100mm(length) board into 4 pieces
Each motor is equipped with cylinder to make the saw blade raise and fail flexibly
Parameter:
Equipment size:2800*1100*1300mm
Total power:maximum 31.5KW
Air pressure:0.5-0.8MP
Voltage:380V
Accuracy:less than 0.1mm
Efficiency:0-35 meters/minute
Equipment related:
Board loading machine S-2460
Board loading&unloading machine L-2460
